Cube Hard Shell Hyperbaric Oxygen Chamber

Share:

Cube Hard Shell Hyperbaric Oxygen Chamber

Custom hard shell hyperbaric oxygen chamber, single person, double person, multiple person options.


ItemSingle chamberDouble chamberMultiple chamber
Size2070mm×1100mm×1800mm       2100mm×1500mm×1800mm2100mm×1800mm×1800m
Cabin materialcarbon steelcarbon steelcarbon steel
Plate thickness2.5carbon steel2.5carbon steel2.5carbon steel
Cabin weight660kg            780kg            860kg
area covered2.3㎡3.2㎡/4.2㎡3.8㎡/4.5㎡
Total power600W-1000W600W-1000W600W-1000W
Oxygen flow rate5L20L20L
oxygen concentration90%±590%±590%±5
pressure10-30kpa10-30kpa10-30kpa
Control cabinet size530*530*880mm500mm×450mm×1070mm
Control cabinet weight58kg                                                                   68kg
Power Supply110v/220v50/60Hz

Contact us now for more infos and best price!
